Gala NOBLE Dual flush valve for ceramic cistern, with blue square dual flush 5035700

Gala NOBLE Dual flush valve for ceramic cistern, with blue square dual flush 5035700

Please note:
This has now been replaced with flush valve and Button 272.400.21.1
this will fit the original cradle and overflow just pull out the old one and plug in the new version the button will have to be changed which comes with the new flush valve.

For installation in ceramic cisternshideCharacteristicsOverflow pipe height-adjustable
Adjustable flush volume depending on amount of water in cistern
Dual flush actuator with threaded rod for fastening the cistern coverhideTechnical dataFlush volume large range 6 / 9 l
Flush volume small range 3-4 l
Actuation force 18 N
Flow pressure range 0.1-10 bar
Operating temperature water max. 25 °C
Max. temperature during storage 40 °C
