Matki Classic Walk-In WSD Square Corner Shower Spare Parts (2008-2015)

Spare Parts

Please Click on POA (Price On Application) to request a price if item is not built on our site yet.
sales@bathroomspareparts.co.uk

Item	Description	Part Number
1	WALL COMPENSATION END	5449AF
2	WALL PLATE	1485AF
3	NYLON SHOULDER WASHER	1644AF
5	TRAY INLET CONNECTOR (TOP)	5450AF
6	TRAY INLET CONNECTOR (BOTTOM)	5442AF
7	TRAY INLET SEALING RING	5484AF
8	TRAY INLET GASKET (BLACK)	5483AF
9	BS4518 O-RING 0400-25	1593AF
10	BS7848 O-RING 0630-30	1591AF
11	CORNER EXTRUSION - GLASS CLAMP	5407ASILVER
13	CORNER EXTRUSION - SCREW HOLES	5409ASILVER
15	GLASS CLAMP - TO TRAY	5491AF
16	GLASS CLAMP GASKET 8mm	5486AF
17	GLASS CLAMP - TO GLASS	5490AF
18	GLASS CLAMP COVER	5493AF
19	M5 X 6MM SKT SET SCREW	1502ASILVER
21	M5 X 20MM SKT SET SCREW	1371ASILVER
22	SQUARE COLUMN FOOT	5488AF
24	CORNER TOP CAP CHROME	5475AF
25	GLASS CLAMP TO TRAY	5491AF
26	M5 X 16MM CSK SKT SCREW	1495ASILVER
27	H SECTION 8MM	5411ASILVER
28	EXT WALL MOUNT	5406ASILVER
29	EXT COVER	5418ASILVER
30	H SECTION END CAP	6215ASILVER
31	EXT W.MOUNT CAP	6216ASILVER
34	WALL MOUNT FOOT (RH)	5478AF
35	WALL MOUNT FOOT (LH)	5477AF
36	NO8 X 32MM PAN HEAD SCREW	1471ASILVER
37	WALL PLUG	1818AF
42	HEADRAIL END CAP (MODEL WSD)	5448AF
43	FINIAL CONNECTOR	1473AF
44	SERVICE AREA CAP	RR0000310
45	M5 X 20MM SLOTTED PAN HEAD SCREW	1278ASILVER
46	FASTFLOW WASTE	FF90CHROME	DISCONTINUED
47	NO6 13MM PAN HEAD SCREW	1432ASILVER
48	M4 X 20MM CSK SKT SCREW (MODEL WSD)	1375ASILVER
49	NO8 X 32MM CSK SELF TAPPING SCREW	1478ASILVER
50	M5 X 12MM HEX SOCKET BUTTON HEAD SCREW	1282ASILVER
51	M4 X 8MM HEX SOCKET BUTTON HEAD SCREW	1276ASILVER
53	BS4518 O-RING 0046-24	1585AF
54	HATCH NEOPRENE FOAM CORD	0000310
59	M5 X 20MM CSK SKT SCREW	1503ASILVER
60	ENTRANCE TUBE (MODEL 1250)	5452ASILVER
60	ENTRANCE TUBE (MODEL 1500/1700)	5453ASILVER
61	EXPOSED COLUMN EXTRUSION	5414ASILVER
62	CONCEALED COLUMN EXTRUSION	5405ASILVER
63	BACK COVER (CORIAN)	5540WHITE
64	COLUMN TOP CAP	5469AF
67	EXTERNAL DIVERTER DISC	5443AF
68	INTERNAL TEMPERATURE DISC	5444AF
69	INTERNAL DIVERTER DISC	5445AF
70	EXTERNAL TEMPERATURE DISC	5446AF
71	SPINDLE GASKET	5487AF
77	TREE-LOCK FASTENER	1642AF
78	TREE-LOCK RECEPTACLE	1643AF
79	FRONT COVER	5541WHITE
80	FRONT COVER TOP CAP	5489AF
85	THERMOSTATIC SERVICE KIT	2/5255SERVICEKIT
95	T CONECTOR	5441AF
97	VERTICAL TUBE	5457ASILVER
98	SQUARE SHOWER HEAD	805B
100	BS4518 O-RING 0160-20	1609AF
101	M5 X 25MM CSK SKT SCREW	1412ASILVER
102	M10 X 60MM SKT SET SCREW	1275ASILVER
106	HANDSET HOLDER	EXSLID-LINEAR
112	FLEXIBLE HOSE	FL8010
119	GLAZING WEDGE (12MM) 2000MM	2221CLEAR
113	HANDSET	2008ESP
115	ADJUSTMENT TUBE (MODEL 1250)	5461ASILVER
115	ADJUSTMENT TUBE (MODEL 1500)	5495ASILVER
115	ADJUSTMENT TUBE (MODEL 1700)	5463ASILVER
116	MIDDLE TUBE (MODEL 1250)	5458ASILVER
116	MIDDLE TUBE (MODEL 1500)	5459ASILVER
116	MIDDLE TUBE (MODEL 1700)	5460ASILVER
117	M4 X 14MM SKT SET SCREW	1279ASILVER
118	RUBBER CORNER CAP (WHITE)	7499WHITE
120	ACRYLIC DECKING (1250 MODEL)	RR0000369
120	TECK DECKING (1250 MODEL)	4524DECK
120	TEAK DECKING (1500/1700 MODEL) 513X841MM	4525AF
120	ACRYLIC DECKING (1500/1700 MODEL) 513X841MM	RR0000370
126	NO8 X 9.5MM PAN HEAD SCREW	1420ASILVER
128	NO8 X 38MM CSK SCREW (MODEL WRD)	1443ASILVER
131	BS4518 O-RING 0186-24	1926AF
